Candy Packaging Machine | Premade Pouch for Gummies, Hard Candy & Chocolates
| Nombre De Pièces: | 1 |
| Prix: | Negotiations |
| Emballage Standard: | Emballage standard international pour l'expédition |
| Période De Livraison: | 30 jours |
| Méthode De Paiement: | LC, T/T, Western Union |
| Capacité D'approvisionnement: | 300 ensembles par an |
If you manufacture gummy bears, hard candies, chocolate beans, or lollipops, you know how important pouch presentation is. This stand-up and zipper pouch packing machine is built for the candy industry, handling everything from sticky gummies to free-flowing hard candies without product damage.
The machine uses a premade pouch feeding system, so delicate candies never pass through a forming tube. This is especially critical for chocolate-coated products and soft gummies that would smear or deform in vertical form-fill-seal equipment.
Our filler can be equipped with a servo-driven cup filler, belt feeder, or counting system depending on your candy type. For example:
Gummy bears → gentle volumetric cup
Hard candies → multi-lane counting system
Chocolate beans → low-impact gravity filler
The sealing system is temperature-controlled, ensuring proper seals even with dusted or oil-coated candies. For zipper bags, an automatic zipper slider and presser ensure the zipper remains functional after sealing.
Common pouch styles for candy include:
Stand-up pouches with tear notch
Resealable zipper bags for sharing packs
Small flat pouches for single servings
Window pouches for premium chocolates
Speed ranges from 20 to 50 pouches per minute depending on bag size and candy type. Changeover parts are tool-less and color-coded for quick cleaning between batches — essential for co-packers handling multiple candy SKUs.
Video proof available: We can run your candy sample on our demo machine and send you the video before order.
| Model | WG-210 | WG-250 | WG-300 |
|---|---|---|---|
| Bag Size | Length: 120-380mm Width: 90-210mm |
Length: ≤400mm Width: 130-260mm |
Length: ≤400mm Width: 160-300mm |
| Packing Speed | ≤70 bags/min | ≤70 bags/min | ≤65 bags/min |
| Work Stations | 8 | 8 | 8 |
| Packaging Formats | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches | Flat bags, stand-up pouches, zipper bags, composite film pouches |
| Power Supply | 380V | 380V | 380V |
| Total Power | 8Kw | 8Kw | 8Kw |
| Air Consumption | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min | 5-7kg/cm²; 0.4m³/min |
| Film Material | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films | Single PE, PE composite film, paper film, various composite films |
| Machine Weight | 500kg | 580kg | 850kg |
| Machine Dimensions | 1700*1140*1470 mm | 1850*1250*1520 mm | 2100*1500*1520 mm |
- Designed in accordance with GMP standards and CE certified
- Full servo control system for reliable, fast, and precise operation
- Empty bag tracking and monitoring device prevents sealing without bag opening, saving packaging materials
- Eight-station structure with centralized control via programmable PLC and six flat touch screens for simple operation
